Control valves and nozzles
KGK-400 series automatic metering valve
( 3 Customer Reviews )This system can be easily designed for the purpose of use simply by connecting an automatic metering valve operated by an air signal and a three-way air valve that sends an air signal. Moreover, since the device is small and lightweight, it can be easily integrated into other devices. Use a three-way air valve with good workability, such as a hand valve or a foot valve.
If a 3-way solenoid valve is used, an electric control system is also possible. Select grease (KGK-402M to 408M) according to the material used.
Grease (oil)
Adhesive (Fluoroplastic packing specification only)
Various types from 0 to 50mL
| Product No | Model | Quantitative value |
|---|---|---|
| 686405 | KGK-401M | 0.05 ~ 0.5mL |
| 686406 | KGK-402M | 0.2-1mL |
| 686407 | KGK-404M | 0.3-3mL |
| 686408 | KGK-405M | 2-5mL |
| 686409 | KGK-406M | 4-10mL |
| 686410 | KGK-407M | 8-20mL |
| 686411 | KGK-408M | 15-50mL |
| Product No | Model | Quantitative value |
|---|---|---|
| 686418 | KGK-401MS | 0.05 ~ 0.5mL |
| 686419 | KGK-402MS | 0.2-1mL |
| 686420 | KGK-404MS | 0.3-3mL |
| 686421 | KGK-405MS | 2-5mL |
| 686422 | KGK-406MS | 4-10mL |
| 686423 | KGK-407MS | 8-20mL |
| 686424 | KGK-408MS | 15-50mL |
| KGK-402M | 119mm |
| KGK-404M | 134mm |
| KGK-405M | 155mm |
| KGK-406M | 187mm |
| KGK-407M | 238mm |
